Filter cloth

Polyester blended filter cloth

air filter cloth
air filter cloth air filter cloth

Polyester blended filter cloth

Technical Specification:

Media:PE

Operating temperature:130℃-150℃

Resistance to Hydrolysis:restricted
Resistance to Acids:good
Resistance to Alkalis:restricted
Resistance to Oxidation:good





  • Order(MOQ):

    1
INQUIRE now
  • Product Detail

Production：

500gsm antistatic  polyester needle punched felt

Construction

Needle Felt

Fibre Composition

Polyester+Conductive fibre

Scrim Composition

Polyester

Felt Area Weight

500g/m2

Thickness

1.7mm

Mean Air Permeability

15(m3/m2/min@200pa)

Breaking Strength-MD(warp)

≥1000

Breaking Strength-CMD(weft)

≥1200

Breaking Elongation(N/5cm)-MD (warp)

≤35

Breaking Elongation(N/5cm)-CMD (weft)

≤60

Dry shrinkage MD(130℃warp )

≤1.5

Dry shrinkage CMD(130℃weft )

≤1.0

Operating Temperatures

≤130 deg C

Recommended Maximum Continuous

130 deg C

Recommended Maximum Surge

150 deg C

Finish

Heat set/singed/calendered



Leave A Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
